Description
Repair rust bubbles, deep scratches, or repaint a replaced part with Volvo spray paint, matched to your factory color code.
Available for popular Volvo paint codes like 019, 426, 452, 455, 614, 707, 711, 714, 717, 723, 731, and any other Volvo paint code.
Choose your Volvo spray paint kit
1. Volvo spray paint
(for those who already have everything else: primer, clearcoat, surface prep materials, and just need the color-matched paint)
- 1× spray can of custom-mixed base paint (matched to your paint code)
2. Volvo quick-fix spray can
(for a fast, temporary fix)
- 1× spray can of base paint with 1K clearcoat built in (lower durability and gloss than a full two-stage repair)
3. Volvo small spray paint kit
(for those who have already prepped the surface)
- 1× spray can of custom-mixed base paint
- 1× spray can of clearcoat (HB BODY 2K HS if available, else CAR-REP acrylcomp or Radex)
4. Volvo basic paint kit
(for surfaces in good overall condition, no surface damage)
- 25mm Radex masking tape
- Masking film for covering surrounding areas (4m × 5m)
- 0.5m grey matting non-woven abrasive (Mirka if available, else Radex)
- Degreaser spray (Car-Rep if available, else HB-Body)
- 4x Degreaser wipes
- 1× epoxy primer spray (Radex pro-line or Roberlo - appropriate color for your paint)
- 1× spray can of custom-mixed base paint
- 1× spray can of clearcoat (HB BODY 2K HS if available, else CAR-REP acrylcomp or Radex)
5. Volvo large spray kit
(for slight surface damage - surface rust, small rust bubbles, scratches till metal, etc.)
- 25mm Radex masking tape
- Masking film for covering surrounding areas (4m × 5m)
- 0.5m Radex sandpaper for surface cleaning (P120, P180) each
- 1× spray can rust converter and primer (2-in-1) (Chamaleon)
- Plastic putty knife (1 flexible, 1 stiff) (Colad)
- Finishing putty, small package (0.2kg) (Radex or Multifuller)
- 0.5m Radex sandpaper for surface prep (P240, P320, P400, P600)
- 0.5m grey matting non-woven abrasive (Mirka or Radex)
- Degreaser spray (Car-Rep if available, else HB-Body)
- 6x Degreaser wipes
- 1× epoxy primer spray (Radex pro-line or Roberlo - appropriate color for your paint)
- 1× spray can of custom-mixed base paint
- 1× spray can of clearcoat (HB BODY 2K HS if available, else CAR-REP acrylcomp or Radex)
6. Volvo rust & hole damage kit
(for significant surface damage, including significant rust and holes)
- 25mm Radex masking tape
- Masking film for covering surrounding areas (4m × 5m)
- 0.5m Radex sandpaper for surface cleaning (P80, P120, P180) each
- 1× spray can rust converter and primer (2-in-1) (Chamaleon)
- Plastic putty knife (1 flexible, 1 stiff) (Colad)
- Aluminum mesh for holes (U-pol)
- Glass fiber putty (0.4kg) (Radex or Multifuller)
- Finishing putty, small package (0.2kg) (Radex or Multifuller)
- 0.5m Radex sandpaper for surface prep (P240, P320, P400, P600)
- 0.5m grey matting non-woven abrasive (Mirka if available, else Radex)
- Degreaser spray (Car-Rep or HB-Body)
- 8x Degreaser wipes
- 1× epoxy primer spray (Radex pro-line or Roberlo - appropriate color for your paint)
- 1× spray can of custom-mixed base paint
- 1× spray can of clearcoat (HB BODY 2K HS if available, else CAR-REP acrylcomp or Radex)
7. Plastic part spray kit
(for unpainted plastic parts)
- 25mm Radex masking tape
- Masking film for covering surrounding areas (4m × 5m)
- 0.5m grey matting non-woven abrasive (Mirka if available, else Radex)
- Degreaser spray (Car-Rep if available, else HB-Body)
- 4x Degreaser wipes
- 1× plastic primer spray (HB BODY PLASTOFIX if available, Car-Rep or other alternatives otherwise)
- 1× Acrylic primer spray (appropriate color for your paint - Radex or Car-Rep)
- 1× spray can of custom-mixed base paint
- 1× spray can of clearcoat (HB BODY 2K HS if available, else CAR-REP acrylcomp or Radex)
Product images are for illustration only; actual packaging may vary. If a listed brand is unavailable from the factory for more than 2 days, we substitute a similar-quality alternative.
Volvo paint color code list
| Code |
Color name |
| 019 |
Black (Svart) |
| 417 |
Nautic Blue Metallic |
| 426 |
Silver Metallic |
| 452 |
Black Sapphire Metallic |
| 455 |
Titanium Grey Metallic |
| 477 |
Electric / Arrow Silver Metallic |
| 492 |
Savile Grey Metallic |
| 612 |
Passion Red |
| 614 |
Ice White |
| 707 |
Crystal White Pearl Metallic — tri-coat
|
| 711 |
Bright Silver Metallic |
| 714 |
Osmium Grey Metallic |
| 717 |
Onyx Black Metallic |
| 723 |
Denim Blue Metallic |
| 731 |
Platinum Grey Metallic |
Each spray paint is custom-made based on the most popular variant of your color code and is not returnable.
Your code isn't in the list? Order "Other" and note code in the order notes. When ordering tri-coat color code, order additional spray paint can for effect layer.
How to find your Volvo paint code
On most Volvos the paint code is on a sticker in the driver's side door jamb - open the driver's door and look at the vertical surface along the edge of the door frame.
Can't find it? Call Volvo dealer center service/parts department, ask for color code & provide VIN. When ordering tri-coat color code, order additional spray paint can for effect layer.
How much paint do you need?
One spray can covers approximately 1 m² (about one car door, one wing/fender, or one sill). As a rough guide:
- Door, wing/fender, sill: 1 spray can each
- Front or rear bumper, boot/trunk lid: 2 spray cans each
- Full roof or full bonnet/hood: 3 spray cans
Coverage varies depending on the actual car size & tone of paint. Treat these numbers as estimates. If painting larger parts, you will need additional small spray kits (paint and clearcoat).
Spray paint application: key tips
Environment you'll need
- A dust-free work area
- Temperature of at least 15°C (59°F)
- Good lighting
- Roughly 4 hours of free time up to a full day, depending on the condition of the part
- PPE safety (respirator & gloves)
Tips and tricks
- Sand in a cross pattern: two strokes up and down, then two strokes left and right, and repeat. Avoid sanding in only one direction; this prevents deep grooves from forming.
- Matte (scuff) and degrease the surface during preparation, even when it only needs repainting (no sanding or filling) and is already in good condition.
- Place aerosol cans in water at about 50°C (122°F) before use to increase the pressure inside the can. This produces a more even, higher-quality spray. Do not put in hotter water, as the increase in pressure can cause issues to the aerosol!
- Start spraying just off the edge of the part, then move the spray onto the surface without releasing the trigger. The first burst of pressure from any aerosol spits out droplets rather than an even mist. Shake every aerosol can for 3–5 minutes before use.
- Read the instructions on your specific clearcoat, primer, rust converter, and paint before use. Drying times vary by product.
- Prime only the damaged area where possible. Apply paint slightly beyond that area, but clearcoat the entire part/panel to avoid a visible line where the clearcoat starts and stops. If not possible, you will need to sand with P3000 and polish the faded part of clearcoat.
Distances and timing
(verify against your specific product; this varies by manufacturer)
-
Rust converter: 25–30cm from the part, 3–6h between coats (depending on the product), 2–3 coats. 24h cure recommended after the final coat.
-
Primer: 25–30cm from the part, 15 min between coats, 2–3 coats (until evenly covered). 1h after the final coat.
-
Paint: 25–30cm from the part, 15 min between coats, 2–3 coats (until evenly covered). 1h after the final coat.
-
Clearcoat: 15–20cm from the part, 15 min between coats, 2–3 coats (until an even, glossy finish; avoid overspraying, which causes drips/runs). Safe to drive after 12 hours of last coat. Should wait 1 week at 15°C (59°F) to polishing / washing. Fully dried after 1-2 weeks.
Full guide on spray paint fixing here.
